1ST09 PowerBall Sorter
| Conveying speed, m/min | 36 to 100 |
| Max. load, kg | 0.5 to 30 |
| Sorting efficiency, pcs/h | ≤5000 |
| Outer width of the frame, mm | 570, 770, 970 (Are respectively to the G5 series model 517, 717 and 917.) |
| Module length, mm | 720 935 1155 |
| Sorting angle | 30°, 45° |
| Drive type | Gear motor |
| Installation height, mm | ≥350 |
The PowerBall Sorter utilizes a specially constructed powerball. A synchronous belt drives beveled gears which in turn drives the powerball.
The PowerBall Sorter operates as an independent unit.
The PowerBall Sorter can sort single sided and double sided at multiple angles.
It is suitable for diverting and sorting cartons, totes, boxes, bags and other soft packages.
